T320 Compact Tracked Loader Specifications

Extrait du fichier (au format texte) :

T320

Compact Loaders

T320

Specifications
Attachments

Rated operating capacity
Tipping load
Pump capacity  T320
Pump capacity  T320H
System relief at Quick Couplers  T320
System relief at Quick Couplers  T320H
Max. travel speed

1461 kg
4177 kg
80.2 l/min
140.1 l/min
22.4 23.1 MPa
24.6 25.3 MPa
10.6 km/h

Make / Model
Fuel / Cooling
Power
Torque at 1600 RPM ( (ISO9249 EEC)
Number of cylinders
Displacement
Fuel tank capacity

Kubota / V3800-DI-T-BOBCAT
Diesel / Liquid
67.6 kW
310.3 Nm
4
3769 cm3
98.4 l

Operating weight, T320
Operating weight, T320H

4401 kg
4421 kg

Vehicle steering
Loader hydraulics tilt and lift
