Twister
Condensing Stainless Steel
Water Heater
TWI 35-200/45-200

0313279 / R2.6

0424 / UK

Installation, User and Service Manual

Data is subject to change

A.O. Smith Europe
De Run 5305
PO Box 70

T : +31 (0)40 294 2500

5500 AB Veldhoven

info@aosmith.com

The Netherlands

www.aosmithinternational.com

Preface

Copyright
Copyright © 2018 A.O. Smith Water Products Company
All rights reserved.
Nothing from this publication may be copied, reproduced and/or published by means of printing, photocopying or by whatsoever means, without the prior written approval of
A.O. Smith Water Products Company.
A.O. Smith Water Products Company reserves the right to modify specifications in this manual.

Trademarks
Brand names in this manual are registered trademarks of their respective owners.

Warranty
Refer to the appendix Warranty (see 13.7) for the warranty provisions.

Liability
User
A.O. Smith accepts no liability when the water heater is not used correctly and requires the user to:
"
"
