8
6
7
**#8- SCREW
P/N: S276-08R05
(AS REQ'D)
* CYLINDER ESCUTCHEON
P/N: 26-0453-XXX
(AS REQ'D)
D
4
5
RETAINING RING
P/N: R603-25
* CYLINDER SPACER
P/N: 26-0452-XXX
(AS REQ'D)
1
PRODUCT MUST BE INSTALLED
ACCORDING TO ALL APPLICABLE
BUILDING AND LIFE SAFETY CODES
MOUNTING SCREW
#8-32 FHMS x 1/2" LG.
**U-TYPE FASTENER
P/N: 29- 0264
(AS REQ'D)
2
3
D
*** 1/4-20 FHM Screw x 2 1/4" LG.
2 PLCS. P/N: S245-416-40-XXX
CAM
P/N: 22-0955
